Netlist Visualization and Debugging Solution for Gate, SPICE, RTL
회사개요
1990년 6월에 설립된 Concept Engineering 사는 독일 Freiburg 에 본사를 두고 있으며, 회로도 생성 및 시각화를 전문으로 하는 GUI 툴의 엔진을 개발하였습니다. 이 엔진은 EDA 유수업체인 Magma, Atrenta, Jedat, DAFCA, HeedSoft, ProDesign, OASIS, Altos 등의 회사에서 OEM으로 채택되어 각 사의 회로도 확인 툴로도 함께 제공하고 있습니다. 또한 자체의 응용 제품들을 개발하여 전 세계 시장에 영업 및 지원을 함께하고 있습니다.
제품개요
FPGA, ASIC 반도체 및 SoC 설계 시에 개발되는 디자인의 종류로는 RTL, Gate-level Netlist, SPICE Netlist 등이 대표적인데 Concept Engineering 사에서는 이 디자인 데이터에 대하여 빠른 회로도 생성과 시각화를 도와 주고 디버깅을 할 수 있도록 제공합니다. 또한, 코아 엔진인 T-Engine 과, NLview 등을 OEM으로 판매 및 지원하고 있고, 응용제품인 GateVision, SPICEVision STARVision 등의 다양한 툴들을 개발하여 회로도 자동 생성 분야에서는 최고의 기술력과 안정된 제품을 자랑하고 있다.

제품소개 및 혜택
RTLVISION pro
Features |
Benefits |
Ultra fast HDL reader and graphics on the fly |
Graphical representations make it easier to understand, debug, change and implement RTL code |
Interactive Graphic Fragment Navigation shows only critical fragments of the RTL |
Being able to identify and concentrate on a fragment helps to reduce complexity of the debug process and makes it easier to understand and change RTL code |
Automatic clock trees and clock domains extraction and analysis |
Faster detection and resolution of clock domain problems |
Full support for mixed language designs (SystemVerilog, Verilog, VHDL) |
Designers can easily develop and debug today’s most complex heterogeneous designs |
Incremental design compilation |
Design updates can be faster, with only changed areas re-compiled |
Automated design documentation |
New and re-used code can be documented automatically |
Tcl API |
RTLvision PRO can be interfaced with the tool flow and the user can extend functionality to match project needs |
GATEVISION pro
Features |
Benefits |
32/64bit platform and on-the-fly schematic creation |
produces very high speed and capacity |
UserWare API |
Easily add custom capabilities for increased productivity |
Automatic path extraction |
Automatically extracts logic cones from user-defined reference points, and shows onl the relevant portion of the circuit, Reduces complexity in the design for improved and faster debug |
Verilog and EDIF netlist interface |
Easily plugs into almost any design flow |
Search-and-show capability |
Easy location of specific objects shortens debug time |
Design hierarchy browser |
Provides easy navigation through the design hierarchy and gives compact hierarchy overview |
Object cross-probing |
Highlights selected objects in all design views (schematic, logic cone and HDL view) and shortens debug time |
Context-sensitive menus |
Easy-to-use GUI |
SPICEVISION pro
Features |
Benefits |
Creates schematics from Spice files |
Schematics provide easier and faster debugging for complex circuits. Supported dialects include SPICE2, SPICE3, HSPICE, Calibre, CDL, Eldo and PSPICE |
64-bit support (Solaris, AIX, AMD64 Linux, Itanium Linux). |
Higher performance and increased capacity, for larger and more complex designs |
Powerful GUI |
Multiple views, including tree, schematic, cone and source file for increased circuit understanding plus drag and drop between different views |
Cone Window |
Incremental schematic navigation for big designs |
Non-Parasitic view |
Displays CMOS function without parasitic structures for comprehension of circuit |
Tcl UserWare API |
Allows interfacing with tool flow and user customization |
Fragment save |
Fragments of circuits can be saved as Spice file and schematic for future reuse as IP, or for partial simulation |
Schematic export |
Export schematics and schematic fragments into Cadence Virtuoso Schematic Editor and EDIF 2.0.0 schematic files for further optimization and debugging |
Predefined symbols |
Symbols for components (resistors, capacitors, transistors, current and voltage sources etc) supplied as standard; can link to external symbol libraries |
SGVISION pro
Features |
Benefits |
Support for Verilog and SPICE dialects in a single tool |
Engineers can quickly and easily understand and debug mixed-mode designs |
Interactive graphic fragment navigation |
Reduces debug complexity and increases engineering productivity |
Object cross-probing |
By highlighting objects in all design views (schematic, logic cone and source code), helps shorten design and debug time |
Tcl UserWare API |
Allows user customization and interfacing to the design tool flow |
32/64 bit platform support |
Power to cope with the largest mixed-mode SoCs and ASICs |
Non-Parasitic view |
Displays CMOS function without parasitic structures for comprehension of circuit |
Predefined symbols |
Standard symbols for transistors, resistors capacitors etc, supplied. Can link to external symbol library to meet local conventions |
Fragment save |
Fragments of circuits can be saved as Spice file and schematic for future reuse as IP, or for partial simulation |
NLVIEW WIDGETS
Features |
Benefits |
Simple and robust API |
Ensures easy integration and reliable applications |
Production-proven software components |
Performance and quality of application is very high |
Highly customizable component |
Widget and application fit together |
Tcl/Tk, Java, MFC, Qt and Perl/Tk components |
Easily fits into your existing software development flow |
Proprietary algorithms |
Result in easy-to-read schematics and short response times |
On-the-fly schematic creation |
Results in very high speed and capacity |
Bi-directional communication between widget and application |
Allows interaction with the application (e.g. cross-probing, highlighting, attribute display, ballooning) |
Incremental schematic viewing |
Allows interactive modification of schematic fragments |
Windows and LINUX platform support |
Application will work on most hardware platforms |
Built-in RTL and gate-level symbols |
Application works without symbol libraries |
Symbol translation tools |
Provide access to existing symbol libraries |
T-ENGINE
Features |
Benefits |
Simple and robust API |
Ensures easy integration and reliable applications |
Production-proven software components |
Performance and quality of application is very high |
Highly customizable component |
Widget and application fit together |
Tcl/Tk, Java, MFC and ActiveX components |
Easily fits into your existing software development flow |
Proprietary algorithms |
Result in easy-to-read schematics and short response times |
On-the-fly schematic creation |
Results in very high speed and capacity |
Bi-directional communication between widget and application |
Allows interaction with the application (e.g. cross-probing, highlighting, attribute display, ballooning) |
Incremental schematic viewing |
Allows interactive modification of schematic fragments |
Windows and LINUX platform support |
Application will work on most hardware platforms |
Built-in transistor and device-level symbols |
Application works without symbol libraries |
Symbol translation tools |
Provide access to existing symbol libraries |
